40AMP POWER SUPPLY 5V

40AMP POWER SUPPLY 5V

This is a 240W 5V/40A Highly Reliable, Universal AC input/full range single output power supply. They have the approval of UL and CE and come 100% full load burn-in tested and are protected with overload/over and voltage/short circuit. Also included is a 2-year manufacturer’s warranty. Dimensions: 7.96 x 4.4 x 2.0″

Brand: PowerSupply1

Rating: 240W / 5V DC / 40A

Complies with RoHS Directive

AC Input Voltage Range: 85-132/ 170-264VAC Selected by Switch

Input Frequency: 47-63Hz

Inrush Current: Cold Start, 20A/115V, 40A/230V

Input Leakage Current: <0.7mA/230V

Line Regulation (Full Load): <± 0.5%

Output Voltage: 5V DC

Output Voltage Adj. Range: ± 10%

Output Overload Protection: 110-130% Constant Current, Auto Recovery

Output Over Voltage Protection: 115-150%

Withstand Voltage: I/P-O/P: 3.0KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min

Rise Time: 50ms @full load (typical)

Hold Up Time: 20ms @full load (typical)

Operating temp.& humidity: -10°C to 50°C (14°F – 122°F), 20%-93%RH (non-condensing)

Storage temp.& humidity: -20°C to 85°C (-4°F – 185°F), 20%-93%RH (non-condensing)

Safety Standards: GB4943, UL60950, EN60950

EMC Standards: GB9254, EN55022 classA

Cooling Method: Convection

Manufacturer: Hengfu
