CPU Cooling Fan HF-690
Product Details :
- Fan 9.2cm
- Intel Socket 95W ,LGA1155/LGA1156 ,Core i7/i5/i3
- Pentium G .,CPU Radiator ,CPU Fan
- CPU cooler Technical parameters: Ventilator ,Size: Φ92X32mm
- Rated voltage: 12V DC ,Rate current: 0.15A ,Rate power: 1.8W
- Fan speed: 2200 ± 10% RPM ,Max air flow: 40.9 CFM ,Noise: 20dB(A)
- Intel Socket 95W-LGA1155/LGA1156
৳ 500.00৳ 600.00Per Piece -
Authentic Aisilin NO.7389C 32-in-1 Screwdrivers Set
Product Details:
- Brand: Aislinn
- Model: 7389C
- Screwdriver bit material: CR-V
- Torx: T4, T5, T6, T8, T9, T10
- Slotted: 1.5, 2.0, 2.5, 3.0, 4.0
- Phillips: 1.2, 1.5, 2.0, 2.5, 3.0
- Allen: 1.5, 2.0, 2.5, 3.0, 3.5, 4.0
- Star: 0.8, 1.2, 2.0
- Triangle: 2.0, 2.3
- Tri-wing: Y2.0, Y3.0
- U-shaped: U2.3
- 1 x Non-slip Handle
- 1 x Segmented Extension Bar
৳ 450.00৳ 550.00Per Piece -
Hi-Power 550W Power Supply for PC
Product Details :
- Brand- Hi Power
- Power- 550W
- AC Input 220V/50-60Hz
- High efficiency
- Over-Power Protection
- Over-Current Protection
- Short Circuit Protection
- 100% full load burn-in
- Silent 135mm Fan with Auto Fan Speed Control
- Single Strong 12V Rail – Ideal for Gaming Systems
৳ 740.00৳ 840.00Per Piece -
Digital Slide Caliper – Vernier Calipers 6 inch
- Material: Stainless Steel Power .
- Source: one 1.5V button cell Operating .
- temperature: 0°C to 40°C .
- Storage temperature: -10°C to 60°C .
- humidity: <80% Size: 235 x 75 x 10mm.
- Color: silver.
- Product Specifications: Package.
- Contents: 1 x Sliver Electronic Digital LCD Caliper Vernier 1 x Black Plastic Box.
- No warranty or guarantee.
- supplier: Labtex Bangladesh.
৳ 735.00 Per Piece -
BRAND NEW PREET 6049 – 2WD – TRACTOR – 60 HP – AGRICULTURAL TRACTOR – FOUR STROKE DI, 3 CYLINDER – DIESEL ENGINE – BOSCH (FUEL PUMP) – WATER COOLING SYSTEM – PREET 6049 – CENTER GEAR (UNMATCHED POWER & STYLE)
PRODUCT DETAILS:
BRAND NEW PREET 6049 – 2WD – TRACTOR -60 HP
ENGINE: –
- Model / Make: Preet – 6049 Diesel Engine
- Hp Category: 60 hp
- Type: Four Stroke Dl
- No. Of Cylinders: 3 Cylinder, Vertical Inline
- Bore / Stroke: 105 / 118 Mm
- Rated Engine: 2200 Rpm
- Displacement: 4087 Cc
- Fuel Pump: Multi-cylinder Inline(Bosch)
- Air Cleaner Type: Dry
- Cooling System: Water Cooled
TRANSMISSION: –
- Gear Box: 8f + 2R Sliding Mesh
- Clutch: Heavy Duty Dry Dual 280 Mm Cerametallic Friction
- Breaks: Multi Disc Oil Immersed
MIN. TURNING RADIUS: –
- Without Break: 3.75 M
STEERING: –
- Type: Power Steering
HYDRAULIC SYSTEM: –
- Type: 2 Levers, ADDC
- Hydraulic Pump: Gear Type
- Linkage: TPL Category-ll
- Lifting Capacity: 1800 Kg
POWER TAKE OFF: –
- Splines: 6
- Type: Dual Speed Live
- P. T. O. Speed: 540 with GPTO / RPTO (Optional)
CAPACITIES (LITRES): –
- Fuel Tank: 67 L
- Engine Sump: 10 L
- Cooling System: 9.5 L
- Transmission & Hydraulic: 55 L
- Steering System: 2
TYRE SIZE: –
- Front: 7.5 – 16
- Rear: 16.9 – 28
- Weight: 2320 Kg (W / O) ROPS)
ELECTRICAL INSTALLATION: –
- Battery: 12 V, 100 Ah
- Alternator: 12 V, 42 A
- Starter Motor: 12 V, 2.7 Kw
DIMENSIONS: –
- Overall Length: 3800 Mm
- Width: 1930 Mm
- Height up to Exhaust: 2280 Mm
- Ground Clearance: 415 Mm
- Wheel Base: 2260 Mm
- Front / Rear Truck: 1425 Mm / 1480 Mm
৳ 0.00 Per Unit -
BRAND NEW PREET 955 – 2WD – TRACTOR – 50 HP – AGRICULTURAL TRACTOR – FOUR STROKE DI, 3 CYLINDER – DIESEL ENGINE – BOSCH (FUEL PUMP) – WATER COOLING SYSTEM – PREET 955 (UNMATCHED POWER & STYLE)
PRODUCT DETAILS:
BRAND NEW PREET 955 (5249) – 2WD – TRACTOR – 50 HP
ENGINE: –
- Model / Make: Preet – 5249 Diesel Engine
- Hp Category: 50 hp
- Type: Four Stroke Dl
- No. Of Cylinders: 3 Cylinder, Vertical Inline
- Bore / Stroke: 105 / 118 Mm
- Rated Engine: 2200 Rpm
- Displacement: 3066 Cc
- Fuel Pump: Multi-cylinder Inline (Bosch)
- Air Cleaner Type: Dry
- Cooling System: Water Cooled
TRANSMISSION: –
- Gear Box: 8f + 2R Sliding Mesh
- Clutch: Heavy Duty Dry Dual 280 Mm Cerametallic Plates
- Breaks: Wet Type / Dry Optional
MIN. TURNING RADIUS: –
- Without Break: 3.35 M
STEERING: –
- Type: Power Steering
HYDRAULIC SYSTEM: –
- Type: 2 Levers, ADDC
- Hydraulic Pump: Gear Type
- Linkage: TPL Category-ll
- Lifting Capacity: 1800 Kg
POWER TAKE OFF: –
- Splines: 6
- P. T. O. Speed: 540 with GPTO / RPTO (Optional)
CAPACITIES (LITRES): –
- Fuel Tank: 67 L
- Engine Sump: 9 L
- Cooling System: 8.5 L
- Transmission & Hydraulic: 55 L
- Steering System: 2
TYRE SIZE: –
- Front: 7.5 – 16
- Rear: 14.9 – 28
- Weight: 2100 Kg
৳ 0.00 Per Unit -
BRAND NEW PREET 4549 – 2WD – TRACTOR – 45 HP – AGRICULTURAL TRACTOR – FOUR STROKE DI, 3 CYLINDER – BOSCH (FUEL PUMP) – WATER COOLING SYSTEM – 4549 THE CHALLENGER (UNMATCHED POWER & STYLE)
PRODUCT DETAILS:
BRAND NEW PREET 4549 – 2WD – TRACTOR – 45 HP
ENGINE: –
- Model / Make: Preet – 4549 Challenger
- Hp Category: 45
- Type: Four Stroke Dl
- No. Of Cylinders: 3 Cylinder, Vertical Inline
- Bore / Stroke: 102 / 118 Mm
- Rated Engine: 2200 Rpm
- Displacement: 2892 Cc
- Fuel Pump: Multi-cylinder Inline (Bosch)
- Air Cleaner Type: Dry
- Cooling System: Water Cooled
TRANSMISSION: –
- Gear Box: 8f + 2r Sliding Mesh
- Clutch: Heavy Duty Dry Dual 280 Mm Cerametallic Plates
- Breaks: Multi Disc Dry Type Mech. / Wet Optional
MIN. TURNING RADIUS: –
- Without Break: 3.45 M
STEERING: –
- Type: Mechanical / Power Steering Optional
HYDRAULIC SYSTEM: –
- Type: 2 Levers, ADDC
- Hydraulic Pump: Gear Type
- Linkage: TPL Category-ll
- Lifting Capacity: 1800 Kg
POWER TAKE OFF: –
- Splines: 6
- P. T. O. Speed: 540 with GPTO / RPTO (Optional)
CAPACITIES (LITRES): –
- Fuel Tank: 67 L
- Engine Sump: 8 L
- Cooling System: 8.5 L
- Transmission & Hydraulic: 55 L
- Steering System: 0.5 (Mech.), 2 (Ps)
TYRE SIZE: –
- Front: 6.00 – 16
- Rear: 13.6 – 28 / 14.9 – 28 (Optional)
- Weight: 2060 Kg
DIMENSIONS: –
- Ground Clearance: 410 Mm
- Wheel Base: 2085 Mm
৳ 0.00 Per unit -
BRAND NEW PREET 4049 – 2WD – TRACTOR – 40 HP – AGRICULTURAL TRACTOR – FOUR STROKE DI, 3 CYLINDER – BOSCH (FUEL PUMP) – WATER COOLING SYSTEM – 4049 THE CHALLENGER (UNMATCHED POWER & STYLE)
PRODUCT DETAILS:
BRAND NEW PREET 4049 – 2WD – TRACTOR – 40 HP
ENGINE: –
- Model / Make: Preet – 4049 Challenger
- HP Category: 40 hp
- Type: Four Stroke Dl
- No. Of Cylinders: 3 Cylinder, Vertical Inline
- Bore / Stroke: 102 / 118 Mm
- Rated Engine: 2200 Rpm
- Displacement: 2892 Cc
- Fuel Pump: Multi-cylinder Inline (Bosch)
- Air Cleaner Type: Dry
- Cooling System: Water Cooled
TRANSMISSION: –
- Gear Box: 8f + 2r Combination of Constant & Sliding Mesh
- Clutch: Heavy Duty Dry Single 280 Mm (Dual Optional) Cerametallic Plates
- Breaks: Multi Disc Dry Type Mech. / Wet Optional
MIN. TURNING RADIUS: –
- Without Break: 3.35 M
STEERING: –
- Type: Mechanical / Power Steering Optional
HYDRAULIC SYSTEM: –
- Type: 2 Levers, ADDC
- Hydraulic Pump: Gear Type
- Linkage: TPL Category-ll
- Lifting Capacity: 1800 Kg
POWER TAKE OFF: –
- Splines: 6
- P. T. O. Speed: 540
CAPACITIES (LITRES): –
- Fuel Tank: 67 L
- Engine Sump: 8 L
- Cooling System: 8.5 L
- Transmission & Hydraulic: 55 L
- Steering System: 0.5 (Mech.), 2 (Ps)
TYRE SIZE: –
- Front: 6.00 – 16
- Rear: 13.6 – 28
- Weight: 2050 Kg
DIMENSIONS: –
- Overall Length: 3700 Mm
- Width: 1765 Mm
- Height up to Exhaust: 2255 Mm
- Ground Clearance: 410 Mm
৳ 0.00 Per Unit -
Mahindra 605 Arjun DI Ultra, The new generation 57 HP engine power, Technologically advance engine tractor- Heavy-duty transmission, comfortable work environment- Lift capacity 1650 kg
Products Details:
- Brand: Mahindra
- Model Number: Mahindra 605 Arjun DI Ultra
- No of Cylinder: 4
- Engine Type: 4 Stroke, Direct injection water-cooled diesel engine
- Engine Power: 57 HP @ 2100 rpm
- Number of Gears: 8F+2R
- Lift Capacity: 1650 kg
- Clutch type: Duel
- Transmission type: Constant Mesh
- Brake Type: Oil Immersed Brakes
- TYRE: 7.50 x16, 16.9 x 28
- Overall Weight: 2420
- Total Lenth: 3480 mm
- Wheelbase: 1970 mm
৳ 1,250,000.00 Per Piece -
Cable Connectors
Product Details :
- Brand: Sun High Welding Equipment
- Product Type: Cable Connectors
- Gigabit Ethernet network
- Plug maintains high bandwidth
৳ 70.00 -
Welding Wire
Product Details:
- Brand: Sun High Welding Equipment
- Product Type: Welding Wire
- Wire Material: Aluminium/Aluminium Alloy
৳ 145.00 -
Welding Mask
Product Details:
- Brand: Sunhigh Welding
- Product Type: Welding Mask
- Helmet Material: High Impact Polyamide-Nylon
৳ 652.00 -
Easy installation Hand Held Ultrasonic Mini Water Oil Flow Meter GMF200-H
Product Overview
GMF200-H series hand-held ultrasonic flowmeter realizes non-contact measurement of liquid flow. Install the sensor on the outer wall of the pipe to complete the flow measurement. With small size, easy to carry, accurate measurement and so on.
Widely used in tap water, heating, water conservancy, metallurgy, chemical, machinery, energy and other industries. It can be used for production monitoring, flow calibration, temporary detection, flow inspection, water meter balance debugging, heating network balance debugging, and energy saving monitoring. It is a necessary tool for timely flow detection.৳ 0.00Per Piece -
Plug-in DN50-DN6000 4-20mA current output, impedance 0-1K, accuracy 0.1% Liquid ultrasonic flow meter
Product overview
GMF200-B plug-in ultrasonic flowmeter is composed of a main body and an external clip type sensor. Simply attach the clip-on sensor to the surface of the pipe to complete the flow measurement of various liquids. Compared with the traditional flow meter, it does not need to cut off the tube, and the installation is quick and convenient, realizing the non-destructive installation.
The main unit can be installed in the wall, instrument box and distribution box, and the protection level can reach IP67. The external clip type sensor is installed on the surface of the pipe, and different sensors are selected. The applicable diameter is DN50~DN6000.
৳ 0.00Per Piece -
Ultrasonic Level Transmitter
Product Overview
GML601-A general-purpose ultrasonic material (liquid) position meter is a Powerful ultrasonic level transmitter, which has taken advantage of many kinds of level instruments at home and abroad. The universal level meter with full digital and humanized design concept has perfect level measurement and control, data transmission and human-computer communication. This product adopts modular circuit design, military quality multi-layer PCB board, compact hardware structure, and reasonable layout. This product supports isolated 4-20mA output, built-in GPRS, RF, LORA, Bluetooth, Wifi to achieve wireless data transmission such as the Internet of Things, support MiniSD card data acquisition or USB storage, can also add modules to achieve other functions according to customer needs.
GML601-A uses imported industrial-grade chips, digital temperature compensation, etc… related ASICs. It has a strong anti-interference ability, can set arbitrarily upper and lower limit nodes and online output adjustment, and has an on-site display. The outer casing is made of engineering plastic ABS waterproof casing, and the casing is compact and quite sturdy. This product can meet most liquid level and material level measurement requirements without touching industrial media, and completely solves the shortcomings such as winding, clogging, leakage, medium corrosion and inconvenience caused by traditional measurement methods such as pressure type, capacitance type, and float type. Therefore, it can be widely used in various fields related to material level and liquid level measurement and control. This product has been tested and approved by the national authority. This product meets the requirements of GB3836.1-2010 and GB3836.4-20010 national standards. The explosion-proof mark is ExiaIIBT4Gb.
Technical Parameter
Range 0~40m (selected when ordering) Blind zone <0.25-2m (different depending on the range) Display resolution 1mm (minimum) Frequency 20KHz ~ 2000KHz Accuracy ±0.25%FS Temperature compensation Automatic temperature compensation Display Four eight-segment LED digital tube, OLED Chinese and English menu Output Analog output signal: 0 ~ 20mA; 4 ~ 20mA load > 300Ω; 0 ~ 5V; 0 ~ 10V RS-485 (supports Modbus) Three-way NPN Power supply DC12～28V；AC220V Power consumption <1.5W Dimensions Φ74mm×132mm×G1 1/2(2m range)
Φ92mm×198mm×M60(5m~15m range) Φ92mm×270mm×DN80Non-standard flange(20m~40m range) Installation interface M30×1.5, G1 1/2 Shell material ABS engineering plastic or nylon Protection level IP65 (can be customized for a higher degree of protection) Explosion-proof grade EXiaIIBT4Gb (selected when ordering) Working environment Normal Temperature and normal pressure Storage humidity ≤80%RH without condensation ৳ 0.00Per PieceUltrasonic Level Transmitter
MOQ: 1 -
Small size IP68 high accurary RS485 cheap card type ultrasonic water meter
GMF200-S Card type Ultrasonic Water Meter
Product features
● Small and compact all plastic, IP68 protection level
● High accuracy 100:1 turndown ratio
● Pipe body probe, not easy to scale
● Adaptive ultrasonic signal can measure water with impurities
● Single chip SOC digital time difference processing
● Multi-line with status display, touch key operation
● Optional built-in Lora or NB-iot function
● Dual interface RS485 and MBUS
● MODBUS, MBUS, CJ188 and other multiple communication protocols
●Can work with external power supply
● Built-in battery 10 years working life
●Reliable and low price suitable for mass applicationProduct parameter
GMF200 Series Ultrasonic Water Meter Model GMF200-S Executive standard ISO4064-2005, GB/T778-2007, JJG162-2009 Measuring fluid Water, sewage, sea water (other fluids need to be customized), and filled with pipe sections Fluid temperature 0.1～+30°C Working environment Temperature: -30 ° C ~ +45 ° C; humidity ≤ 100% (RH) Under pressure 1.6Mpa Pressure loss No pressure loss Upstream flow field U5 Downstream flow field D3 Security Level Class C Electromagnetic Compatibili E2 level Communication Interface RS-485/USART/infrared Output signal Two isolated OCT or TTL pulse output / 1 two-wire 4-20mA analog output Power supply
Built-in lithium battery (3.6V, 19Ah) / external DC8~30V DC power supply / two-wire 4-20mA power supply Protection level IP68 (can work 2 meters underwater) Local display
Dual line display includes 9-bit cumulative, 4-bit instantaneous flow, and various status prompts and units Data storage
Use FRAM/FLASH storage parameters to automatically record the cumulative flow of the first 512 days Flow measurement cycle Measurement status: 1 time/second; verification status: 4 times/second Power consumption Battery used for 20 years Dimensional drawing (mm) specific size, please contact the manufacturer ৳ 0.00Per Piece -
GMF200-P Portable Ultrasonic Flow Transmitter
GMF200-P Portable Ultrasonic Flow Transmitter
Product Overview
GMF200-P series of portable ultrasonic flowmeters enables non-contact measurement of liquid flow. Install the sensor on the outer wall of the pipeline to complete the flow measurement, which is convenient and accurate. Built-in printer and SD card memory, you can print the set measurement value instantly or regularly.
Widely used in tap water, heating, water conservancy, metallurgy, chemical, machinery, energy and other industries. Can be used for production monitoring, flow calibration, temporary detection, flow inspection, water meter balance debugging, heating network balance debugging, energy saving monitoringTechnical Parameters
GMF200 Series Ultrasonic Flowmeter Model GMF200-H Principle Ultrasonic time difference principle Precision ±1% Display 4×8 Chinese or 4×16 Western dot matrix backlit LCD, supporting Chinese, English, Italian and French languages Output 1 channel 4-20mA output
1 channel OCT pulse output (pulse width 6-1000ms, default 200ms)
1 channel relay output
Data interface Isolating the RS-232 application interface, the flow meter can be upgraded through a PC Pipe Steel, stainless steel, cast iron, copper, PVC, aluminum, fiberglass, and other dense pipes, allowing lining Pipe inner diameter 15-6000mm Straight pipe The sensor installation point is best to meet: upstream 10D, downstream 5D, from the pump outlet 30D (D is the pipe diameter) Medium Water, sea water, sewage, acid and alkali, alcohol, beer, various oils, etc. Fluid temperature -30~+160°C Turbidity 1000pmm bubble content is small Flow rate 0～±10m/s Working environment Host: -20 ~ +60 ° C; flow sensor: -30 ~ +160 ° C Host: 85% RH; sensor protection grade: IP67 Power supply 3-cell rechargeable Ni-MH battery with 1.2V capacity of 2000mAH, which can work continuously for more than 12 hours every time. Power consumption 1W Housing material Flame retardant ABS Host weight 390g ৳ 0.00Per Piece -
Panel Mounted External Clip Type Ultrasonic Flowmeter
GMF200-B Panel mounted external clip type ultrasonic flowmeter
Product overview
GMF200 -B Series external type ultrasonic flowmeter is transmitted by the host and the external clip type sensor composition.
Just attach the outer clip sensor to the surface of the pipeline to complete the flow measurement of various liquids. Compared with traditional flow meters, it does not need to cut off the pipe and flow, and the installation is quick and easy.Technical parameters
Working environment
Host Sensor Protection level IP67 IP68 Humidity ≤85%RH Temperature -20℃-60℃ -30℃-160℃ Basic parameters
Accuracy ±1% Flow velocity 0~±10m/s Pipe diameter DN15-DN6000 Fluid temperature -30℃-160℃ Fluid type Water, seawater, industrial sewage, acid and alkali, alcohol, beer, various oils, and other single homogeneous liquids that can conduct ultrasonic waves. Pipe material All dense pipes such as steel, stainless steel, cast iron, steel, PVC, aluminum, and glass-reinforced plastic are allowed to be lined. Signal output 1 channel 4-20mA current output, impedance 0-1K, accuracy 0.1% (optional)
1 channel OCT pulse output (pulse width 6-1000ms, default 200ms)
1 channel Relay output
Signal input 3 channel 4-20mA current input,
A three-wire PT100 platinum resistor can be connected to thermal measurement.
Communication Interface Isolated RS485 serial interface, support MODBUS protocol Data storage SD card timing storage setting parameters and measurement results (optional) Power supply DC8~36V or AC85~264V Product features
1.The host is used for dashboard installation.
2.The external sensor is installed on the surface of the pipeline. Choose different sensors, applicable caliber: DN15 ~ DN6000.৳ 0.00Per Piece -
Segment Tube Type IP68 Ultrasonic Liquid Flow Meter
GMF200-D Pipe type ultrasonic flowmeter
Product overview
Pipe type ultrasonic flowmeter is composed of a main body and a pipe segment type sensor. The DN15-DN32 uses a π-type pipe segment sensor, and the DN40 and above uses a standard pipe segment sensor. The pipe-type ultrasonic flowmeter has the advantages of simple installation, low starting flow, high measurement accuracy, and no pressure loss.
The main unit can be installed in the wall, instrument box, and distribution box with a protection level of IP67. The external clip sensor is installed on the surface of the pipe and selects different sensors. The applicable diameter is DN15~DN6000.
Technical parameters
Working environment
Host Sensor Protection level IP68 IP68 Humidity ≤85%RH Temperature -20℃-60℃ -30℃-160℃ Basic parameters
Accuracy ±0.5% Flow velocity 0~±10m/s Pipe diameter DN15-DN6000 Fluid temperature -30℃-160℃ Fluid type Water, sea water, industrial sewage, acid and alkali, alcohol, beer, various oils and other single homogeneous liquids that can conduct ultrasonic waves. Pipe material All dense pipes such as steel, stainless steel, cast iron, steel, PVC, aluminum, and glass reinforced plastic are allowed to be lined. Signal output 1 channel 4-20mA current output, impedance 0-1K, accuracy 0.1% (optional)
1 channel OCT pulse output (pulse width 6-1000ms, default 200ms)
1 channel Relay output
Signal input 3 channel 4-20mA current input,
A three-wire PT100 platinum resistor can be connected for thermal measurement.
Communication Interface Isolated RS485 serial interface, support MODBUS protocol Data storage SD card timing storage setting parameters and measurement results (optional) Power supply DC8~36V or AC85~264V or AC10~30V Product features
1.Simple installation, no need for professional workers
2.High precision and low price3.Can work in humid and water-immersed environment
৳ 0.00Per Piece -
4-20mA High Accuracy RS485 GML601-C High Precision Small Blind Spot Ultrasonic Level Transmitter
GML601-C High Precision Small Blind Spot Ultrasonic Level Transmitter
Product Overview
GML601-C high precision small blind spot ultrasonic level transmitter is developed by our company for small blind zone, high precision and small space working condition control. China’s first ultrasonic ranging product with a blind zone of less than 0.06m and an accuracy of ± 1mm (has won the National Science and Technology Innovation Fund Project Award, Chongqing High-tech New Product, and Chongqing Key New Product). The shell is made of ABS engineering plastic waterproof shell, the probe part is PP or stainless steel, the shell is small and very sturdy; the transparent main cover is designed for easy observation and display. The main chip adopts imported industrial-grade
single-chip microcomputers, digital temperature compensation, and ultra-wide voltage input voltage regulators, including dozens of related application-specific integrated circuits, to make the product performance more stable and more reliable. It has strong anti-interference ability. It can set the upper and lower limit nodes and online output adjustment arbitrarily through the host computer software. It can choose analog quantity, switch quantity and RS485 output, which is convenient to interface with related facilities. It has high reliability, no pollution, stable performance, and can meet most liquid level and material level measurement requirements without contacting industrial media. It completely solves the shortcomings of entanglement, blockage, leakage, medium corrosion and inconvenience caused by traditional measurement methods such as pressure, capacitance, and float. Therefore, it can be widely used in various fields related to material level and liquid level measurement and control. This product has been inspected and approved by the national authority. This product complies with the national standard requirements of GB3836.1-2010 and GB3836.4-20010. The explosion-proof mark is ExiaIIBT4Gb.
Technical Parameter
Performance Range 1m, 2m (selected when ordering) Dead zone <0.06-0.15m (different from range) Launch angle Less than 6 ° (depending on the sensor) Minimum display
resolution
1mm Maximum error Less than ± 1mm, less than ± 1.5mm (different from range) Working frequency 40KHz~430.0KHz (different due to model specifications) Temperature
compensation
Automatic temperature compensation Display Four-digit eight-segment LED digital tube, OLED Chinese and English menu
(with self-luminous)
Site setup Completed by local keys Calibration Factory calibration and field calibration Output (selected when ordering) Analog output signal 0~20mA; 4~20mA load> 300Ω; 0~5V; 1~5V; 0~10V;
1~10V
Digital output RS485 (supports Modbus) Switch output Triple NPN Power Operating Voltage DC12-24V Power consumption <1.5W Physical properties Dimensions Φ74mm × 92mm × M30 (stainless steel);
Φ74mm × 117mm × G1 1/2 (ABS)
Installation method M30 × 1.5, G1 1/2 shell material ABS engineering plastics; Transducer Stainless steel or ABS engineering plastic Keypad Three-position patch A, B, C keyboard Outlet method Meter standard socket or cable 1.5M (optional arbitrary length) Environmental performance Protection class IP65 (customizable higher protection level) Explosion-proof
grade
EXiaII BT4Gb (selected when ordering) working
environment
Temperature and pressure Storage humidity ≤80% RH without condensation Product Features
1. Sturdy and stable sensor suitable for harsh industrial occasions
2. Strong anti-interference, can set the upper and lower limit nodes and online output adjustment
3. Built-in temperature sensor in the transducer, real-time automatic temperature compensation of measured values
4.4~20MA current output, optional fieldbus interface
5.The first domestic 0.06m small blind spot level gauge
৳ 0.00Per Piece
Shop By Department
- Apparel, Textile and Garments
- Beauty and Personal Care
- Baby Care
- Bath and Soap
- Beauty Equipment
- Breast Care
- Feminine Hygiene
- Foot Care
- Fragrances and Deodorant
- Hair Care
- Hair Extension and Wigs
- Hair Saloon Equipment
- Makeup or Makeup Tools
- Nail Care or Nail Supplies
- Napkin or Wet paper or Diaper
- Oral Care
- Other Beauty and Personal Care
- Shaving and Hair Removal
- Skin Care or Skin Care Tools
- Construction and Building
- Building and Construction Materials
- Constraction Safety Materials
- Construction Material
- Electrical Equipments
- Elevators and Escalators
- Glass Steel and Pipe
- Machineries Equipment and Vehicle
- Planing Design and Decoration Services
- Sanitaryware and Fittings
- Security and Protection
- Service
- Timber, Door and Window
- Tools and Hardware
- Electrical and Electronics
- Air Conditioner
- Bluetooth Earphones and Headphones
- Camera
- Coller and Ventilation
- Consumer electronics
- Freezer and Refrigerator
- Laptop and Desktop Accesories
- Lights and Bulbs
- Mobile and Accessories
- Smart Accesories
- Solar Products
- Speaker and Microphone
- Switch and Socket
- Telecommunication and Security
- Television
- Fashion Accessories
- Furniture and Decoration
- Antique Furniture
- Baby Furniture
- Bamboo and Rattan Furniture
- Carpet, FloorMat, WallMat and DoorMat
- Decoration Material
- Furniture Accessories
- Furniture Machienery Parts
- Glass Furniture
- Handicraft
- Home Furniture
- Metal Furniture
- Office and Industrial Furniture
- Plastic Furniture
- Showpieces
- Wood and Glass Cleaner
- Wood Furniture
- Health and Medical
- Adult Products
- Consumer
- Cosmetics and Personal Care
- Covid19
- Diagnosis Instruments
- Exercise and Fitness Equipment
- Food Supplements
- Health and Medicine
- Herbal and Ayurvedic Medicine
- Medical and Surgical
- Medical Equipments
- Medical Supplies
- Medicine and Health Products
- Medicines
- Pharmaceutical Machinery and Parts
- Home and Kitchen
- Air Conditioner
- Air Purifier
- Blender and Juicer
- Cleaning Appliance
- Coffee Maker or Electric Kettle
- Fan and Lights
- Household Cleaning Tools and Accessories
- Kitchen Appliances
- Laundry Appliances
- Microwave Oven
- Pest Control
- Refrigerator and Freezer
- Room Heater
- Towels and Covers
- Washing Machine
- Water dispenser
- Water heater
- Water softener and Purifier
- Industry and Office Appliances
- IT Services
- Leather Accessories
- Machinery and Industrial Supplies
- Apparel and Textile Machinery
- Building and Construction Machinery
- Chemical Machinery and Equipment
- Electronics Manufacturing Machinery
- Firming and Fishery machinery
- Food and Beverage Machinery
- Footwear Production Machinery
- Forest Machinery and Parts
- Furniture or Woodworking Machinery
- General Industrial Equipments
- Jute Machinery and Parts
- Leather Machinery and parts
- Metal Processing Machinery
- Metallurgy Machinery and Parts
- Packaging Machinery
- Paper Production
- Pharmaceutical Machinery and Parts
- Photographic Equipments
- Plastic and Rubber Machinery
- Machinery and Hardware
- Other
- Paper, Printing and Packaging
- Security Appliances
- Services
- Stationery
- Stationery and Craft
- Tax, Vat, Accounting and Legal Services
- Vehicles
Become a Seller
Hotline: 09612200600
01313432889
01313432889
