BRAND NEW SANY HEAVY ENERGY – 2500 KW WIND TURBINE GENERATOR – SE14125 WTG – HIGH SPEED – DOUBLE FED – HIGH POWER GENERATION AND HIGH RELIABILITY – LOW CONSTRUCTION COST AND LOW MAINTENANCE COSTS

৳ 1.00 Per Unit

In stock

PRODUCT DETAILS:

SANY HEAVY ENERGY – 2500 KW WIND TURBINE GENERATOR – SE14125 WTG

MODEL: 905 2.X ULTRA-LOW SPEED WTG

  • Rated Power: 2500 Kw
  • Cut-in Wind Speed: 3 M/s
  • Cut-out Wind Speed: 20 M/s
  • Ambient Temperature Range- Operation: -10°c ~ 40°c (Standard Temperature)/ -30°c ~ 40°c (Low Temperature)
  • Ambient Temperature Range- General: -20°c ~ 50°c (Standard Temperature)/ -40°c ~ 50°c (Low Temperature)
  • Design Class: IEC S

ROTOR: –

  • Rotor Diameter: 141m
  • Swept Area: 15284m2
  • Power Control: Variable Speed Variable Pitch

TRANSMISSION CHAIN: –

  • Gearbox: Two-stage Planetary, One Stage Parallel Gearbox

GENERATOR: –

  • Type: DIFG
  • Voltage: 690 V
  • Frequency: 50/60 Hz
  • Cooling System: Forced Air Cooling System

YAW SYSTEM: –

  • Type: Gear Motor Reducer
  • Braking System: Hydraulic Disc Brakes

TOWER: –

  • Material: Steel
  • Hub Height: 85m | 90m | 100m | 120m | 130m | 140m
Download Shodagor mobile app for quick order. Install App
MOQ: 1
Start Order

  Contact Seller

SANY HEAVY ENERGY – 2500 KW WIND
TURBINE GENERATOR – SE14125 WTG – HIGH SPEED – DOUBLE FED – HIGH POWER
GENERATION AND HIGH RELIABILITY – LOW CONSTRUCTION COST AND LOW MAINTENANCE
COSTS:

The 2.X series is characterized by European design and they combine the features “high, large, long, light and intelligent” of SANY products, which can be applied to the wind farm with medium and low speed. In the wind farm with annual average wind speed of 4.8m/s, the equivalent generating hours are over 2,000h.

FEATURES:

  • High Match 140M Tower, The Highest Within Industry
  • Large Power Coverage Area: 1.8 – 2.5MW
  • Long Match Rotor Diameter 105-141 Blades
  • Light Load Shedding and Structural Optimization
  • Intelligence Precise Synchronous Variable-Pitch, Grid Friendly and Highly-Integrated smart Control

SANY focuses on the customer requirements by providing most efficient wind turbines in the market. The unique characteristics of SANY wind turbines are:

  • High Power Output
  • High Reliability
  • Low Maintenance Cost
  • The quality of SANY wind turbines is governed by:
  • Quality Control in Component Selection and Manufacturing
  • Efficient O&M Support
  • Spare Parts Availability
  • Comprehensive test system guarantee the quality of our wind turbine generators.

For both onshore and offshore wind power projects, you can always find machines from SANY that satisfy your requirements.

Key Features of SE14125 – 2.5 MW Wind Turbine are as follows.

  • Most Efficient Wind Turbine in its Class in India
  • Designed for Low-medium Wind Regime Conditions
  • High Efficiency and Availability

Wind Power Solution Provider

Customized Products and Service

SANY custom designs the 2.0MW wind turbine generators to meet your business needs and provides you with the integrated solutions covering site selection, wind assessment, construction, equipment installation and operation of wind farms.

High Productivity

Optimal CP Operation Technology

The optimal CP operation technology greatly increases the turbine’s speed regulating range; thus, the turbine can run with optimal capacity before reaching the rated power. This significantly improves the power curve, power generation capacity and reduces the cut-in speed and rated wind speed.

Low Wind Speed Design

Applying to the condition when the annual average wind speed is lower than 5m/s; reducing cut-in wind speed; and increasing generating capability of low-speed wind period

Hydraulic Yaw Technology

SANY patented real-time yaw can realize precise orientation, capture maximal wind power, and real-time cast loose, and avoid stranded cable.

Wide Adaptability

Good Grid Adaptability

By magnetizing the rotor side of the double-fed WTG, the stator side of the double-fed WTG can output the same voltage and current as the frequency and phase of power grid voltage and carrying out independent active and reactive decoupling control according to requirement.

Converter/Main Control System

By improving the control algorithm, WTG can automatically adjust the power and rotation speed relationship based on environmental changes (such as air density, temperature and humidity) to increase full-power rectification at a low wind speed and generation.

High Reliability

Low Voltage Ride through Capability

The low voltage ride through test and other certifications guarantee that the turbine can respond rapidly during the reduction of voltage, generate the dynamic reactive power to support the recovery of grid voltage, and the active power is recovered rapidly after clearing the fault.

Overload Avoidance Technology

Based on the load condition of each part of turbine, the operating state can be controlled to avoid operation at its component’s limit thus to protect the turbine from damage.

Low Cost

Self-climbing Cranes

This innovative design can realize hoisting and installing of tower, cabin, wind wheel and other large components without using large crawler cranes, helping you save abundant construction time and cost.

Operation and Maintenance Service

SANY makes the “1-2-3-15” service commitment: reply in 1 quarter hour, arrive on site in 2 hours, problem solved in 3 days and serious faults solved in 15 days.
