Small size IP68 high accurary RS485 cheap card type ultrasonic water meter

৳

In stock

GMF200-S Card type Ultrasonic Water Meter

Product features
● Small and compact all plastic, IP68 protection level
● High accuracy 100:1 turndown ratio
● Pipe body probe, not easy to scale
● Adaptive ultrasonic signal can measure water with impurities
● Single chip SOC digital time difference processing
● Multi-line with status display, touch key operation
● Optional built-in Lora or NB-iot function
● Dual interface RS485 and MBUS
● MODBUS, MBUS, CJ188 and other multiple communication protocols
●Can work with external power supply
● Built-in battery 10 years working life
●Reliable and low price suitable for mass application

Product parameter

GMF200 Series Ultrasonic Water Meter
Model GMF200-S
Executive standard ISO4064-2005, GB/T778-2007, JJG162-2009
Measuring fluid Water, sewage, sea water (other fluids need to be customized), and filled with pipe sections
Fluid temperature 0.1~+30°C
Working environment Temperature: -30 ° C ~ +45 ° C; humidity ≤ 100% (RH)
Under pressure 1.6Mpa
Pressure loss No pressure loss
Upstream flow field U5
Downstream flow field D3
Security Level Class C
Electromagnetic Compatibili E2 level
Communication Interface RS-485/USART/infrared
Output signal Two isolated OCT or TTL pulse output / 1 two-wire 4-20mA analog output

Power supply

Built-in lithium battery (3.6V, 19Ah) / external DC8~30V DC power supply / two-wire 4-20mA power supply
Protection level IP68 (can work 2 meters underwater)

Local display

Dual line display includes 9-bit cumulative, 4-bit instantaneous flow, and various status prompts and units

Data storage

Use FRAM/FLASH storage parameters to automatically record the cumulative flow of the first 512 days
Flow measurement cycle Measurement status: 1 time/second; verification status: 4 times/second
Power consumption Battery used for 20 years
Dimensional drawing (mm) specific size, please contact the manufacturer
৳
MOQ: 1
Start Order

  Contact Seller
